Modbus in Node-RED — The 47-Year-Old Protocol Everyone Still Uses

I’ve written about OPC-UA, EtherNet/IP, and a whole zoo of modern protocols. But if I had to bet on which protocol you’ll actually encounter most often on a real shop floor, my money is on the oldest one in the room: Modbus. Designed by Modicon in 1979, it’s on power meters, VFDs, temperature controllers, flow meters, HVAC gear, and ten thousand other devices. It’s gloriously simple, slightly maddening, and absolutely everywhere. Here’s how to talk to it from Node-RED.

Why Modbus Refuses to Die

#

Modbus survives because it asks almost nothing of a device: a tiny stack, no licensing, no certificates, no information model. If a sensor has a microcontroller and a serial port or an Ethernet jack, it can probably speak Modbus. That simplicity is also its weakness — there’s no discovery, no metadata, no built-in typing. You get numbered registers holding 16-bit words, and a vendor PDF that tells you what they mean. That’s the deal.

The Two Flavors: TCP and RTU

#

flowchart LR
    NR["Node-RED"]
    subgraph TCP["Modbus TCP"]
        D1["Power meter<br/><i>192.168.1.50:502</i>"]
    end
    subgraph RTU["Modbus RTU (serial)"]
        GW["RS-485 bus"]
        D2["VFD<br/>unit 1"]
        D3["Temp ctrl<br/>unit 2"]
        D4["Flow meter<br/>unit 3"]
        GW --- D2
        GW --- D3
        GW --- D4
    end
    NR -->|"TCP:502"| D1
    NR -->|"USB-RS485 adapter"| GW

• Modbus TCP — Modbus framing over Ethernet, port 502. One IP per device, addressed directly.
• Modbus RTU — the serial original, over RS-485 (or RS-232). Multiple devices share one bus, each with a unit ID (1–247). You reach the bus through a USB-to-RS485 adapter or a serial-to-Ethernet gateway.

The data model is identical between them — only the transport differs. Code that decodes a register map works the same whether the bytes arrived over TCP or a serial line.

The Four Register Types

#

This is the part the vendor PDF assumes you already know:

90% of the time you want Holding Registers (FC 03) or Input Registers (FC 04). When in doubt, the register map will tell you which.

The Addressing Off-by-One Trap

#

Here is the single most common Modbus mistake. Vendors document registers using 1-based numbering with a type prefix, but the actual protocol address is 0-based and has no prefix:

Vendor documents:   40001  (holding register, "4" prefix, 1-based)
Protocol address:   0      (holding register, 0-based)

Vendor documents:   40108
Protocol address:   107

  Rule:  protocol_address = documented_number - 40001   (for 4xxxx)
                          = documented_number - 30001   (for 3xxxx input regs)

The same offset rule applies to all four address spaces — coils 0xxxx (offset = n−1), discrete inputs 1xxxx (−10001), input registers 3xxxx (−30001), and holding registers 4xxxx (−40001).

If every value you read is shifted by one register, this is why. Some Node-RED nodes and some vendors are already 0-based — always read two registers you know the values of and confirm the offset before trusting anything.

Reading Modbus from Node-RED

#

Install

#

cd ~/.node-red
npm install node-red-contrib-modbus

Configure the Connection

#

Modbus TCP:

Modbus-Client (TCP)
├── Host:     192.168.1.50
├── Port:     502
├── Unit ID:  1
└── Timeout:  1000 ms

Modbus RTU:

Modbus-Client (Serial)
├── Serial port: /dev/ttyUSB0
├── Baud:        9600       (must match device!)
├── Data bits:   8
├── Parity:      none / even   (check the manual)
├── Stop bits:   1
└── Unit ID:     per device

For RTU, every serial setting must match the device exactly — a parity mismatch produces silence or garbage, not a helpful error.

Read Holding Registers

#

A Modbus-Read node configured for FC 03:

Modbus Read
├── Function:  FC 03 - Read Holding Registers
├── Address:   0
├── Quantity:  10
└── Poll rate: 1000 ms

The raw output is an array of 16-bit unsigned integers:

{ "payload": [427, 0, 2450, 0, 1, 1847, 0, 0, 0, 0] }

…which is useless until you decode it.

Decoding: Where the Real Work Is

#

A 16-bit register holds 0–65535. Real-world values — temperatures with decimals, 32-bit counters, floats — span multiple registers and need decoding. This is the part that separates “I got an array of numbers” from “I have a temperature.”

Scaled Integers

#

The most common pattern: the device stores 427 and the manual says “value × 0.1 °C”:

const tempC = msg.payload[0] * 0.1;   // 427 → 42.7 °C

Signed 16-bit

#

Modbus registers are unsigned. A negative temperature comes through as a big number:

function toInt16(u) { return u > 32767 ? u - 65536 : u; }
const temp = toInt16(msg.payload[0]) * 0.1;   // 65436 → -10.0 °C

32-bit Integers and Floats (Two Registers)

#

A 32-bit value occupies two registers, and byte/word order is not standardized — this is the deepest Modbus rabbit hole. The same float can be encoded four different ways:

// Combine two 16-bit registers into a 32-bit float
function toFloat32(regs, i, order = "ABCD") {
    const buf = Buffer.alloc(4);
    const hi = regs[i], lo = regs[i + 1];
    switch (order) {
        case "ABCD": buf.writeUInt16BE(hi, 0); buf.writeUInt16BE(lo, 2); break; // big-endian
        case "CDAB": buf.writeUInt16BE(lo, 0); buf.writeUInt16BE(hi, 2); break; // word-swapped
        case "BADC": buf.writeUInt16LE(hi, 0); buf.writeUInt16LE(lo, 2); break; // byte-swapped
        case "DCBA": buf.writeUInt16LE(lo, 0); buf.writeUInt16LE(hi, 2); break; // fully reversed
    }
    return buf.readFloatBE(0);
}

If a float reads as nonsense (1.2e-38, absurd magnitudes), try the other word order first — CDAB is the usual culprit. There is no way to detect the right order from the data alone; the manual knows, or you brute-force all four against a known value.

Writing Setpoints

#

msg.payload = {
    value: [650],     // array, even for one register
    fc: 6,            // FC 06 - Write Single Holding Register
    address: 100,
    unitid: 1
};
return msg;

For a scaled setpoint, pre-multiply: to write 65.0 °C to a register scaled by 0.1, write 650. The same write-safety rules from the Allen-Bradley post apply — validate ranges and whitelist writable registers. A Modbus write goes straight to the device with zero ceremony.

Common Pitfalls & Troubleshooting

#

Everything Reads Zero or Times Out (TCP)

#

Checklist:
  [ ] Right function code? (FC 03 vs FC 04 — input vs holding)
  [ ] Right unit ID? (often 1, but some gateways use 255 or 0)
  [ ] Off-by-one? (40001 → address 0)
  [ ] Device actually on 502? (some use 503, or a custom port)
  [ ] Only ONE client polling? (cheap devices allow 1 TCP connection)

RTU: Silence or Garbage

#

Serial parameter mismatch, every time. Baud, parity, and stop bits must match exactly. Also check RS-485 wiring polarity (A/B) and that the bus has proper termination resistors (120 Ω) at both ends on long runs.

Values Are Shifted by One Register

#

The 40001-vs-0 addressing trap. Verify against a register whose value you can confirm physically.

Floats Are Nonsense

#

Wrong word order — try CDAB. See the decoding section.

Polling Too Fast Drops Responses

#

Cheap Modbus devices are slow. Hammering a power meter every 100 ms causes timeouts and missed responses. 1–5 second polling is plenty for most Modbus data, and RTU buses especially need breathing room between transactions.

One Slow Device Stalls the Whole RTU Bus

#

On a shared RS-485 bus, requests are serial — a device that’s slow to answer (or offline, causing timeouts) delays everything behind it. Keep per-device timeouts tight and consider splitting busy devices onto their own bus.

Bringing Modbus into the Modern Stack

#

Modbus on its own is a dead end — raw registers nobody else understands. Its value comes from lifting it into your wider architecture. Once decoded in Node-RED, a Modbus power-meter reading is just another msg.payload, indistinguishable from an OPC-UA tag:

• Normalize it and publish to a Unified Namespace alongside your PLC data.
• Stream high-frequency energy data to Kafka for analysis.
• Feed it into predictive maintenance or OEE calculations.

That’s the quiet superpower of using Node-RED as the integration layer: it turns a 47-year-old protocol with no metadata into a first-class citizen of a modern, event-driven plant.

Conclusion

#

Modbus is simple to the point of being primitive, and that’s exactly why it has outlived every protocol meant to replace it. The protocol itself you’ll learn in an afternoon; the gotchas are what cost time — the 40001 addressing offset, signed-integer decoding, and the four-way coin flip of 32-bit word ordering. Internalize those three, validate against values you can physically confirm, poll gently, and Modbus becomes a reliable, ubiquitous data source. On a real shop floor, knowing Modbus cold is worth more than fluency in any shinier protocol — because it’s the one that’s actually on the wall.
