Choosing the right messaging protocol for an Industrial IoT project is one of the most impactful architectural decisions you’ll make. Pick the wrong one and you’ll spend months working around its limitations. Pick the right one and data flows effortlessly from sensor to cloud.

In this post I compare MQTT, Sparkplug B, NATS, and OPC-UA — four protocols I work with daily in industrial environments. No theoretical fluff — just practical differences, real trade-offs, and concrete examples.

The Quick Overview
#

	MQTT	Sparkplug B	NATS	OPC-UA
Origin	IBM, 1999	Eclipse Foundation	CNCF	OPC Foundation
Transport	TCP/WebSocket	MQTT (layer on top)	TCP/WebSocket	TCP/HTTPS
Pattern	Pub/Sub	Pub/Sub	Pub/Sub, Req/Reply, Queue	Client/Server, Pub/Sub
Data Model	None (raw bytes)	Defined (metrics, types)	None (raw bytes)	Rich information model
Persistence	Retained messages	Birth/Death certificates	JetStream streams	Built-in historian
Typical Latency	1–10 ms	1–10 ms	< 1 ms	5–50 ms
Throughput	~100K msg/s	~80K msg/s	~10M msg/s	~50K msg/s
Best For	Simple sensor telemetry	Standardized SCADA	Cloud-native, edge mesh	OT/automation

MQTT — The Universal Connector
#

MQTT is the lingua franca of IoT. Lightweight, simple, and supported by virtually every device and platform. If your sensor has a network stack, it probably speaks MQTT.

How It Works
#

MQTT uses a broker-based publish/subscribe model. Clients publish messages to topics, and other clients subscribe to those topics. The broker handles routing.

Sensor A ──publish──→ ┌──────────┐ ──→ Subscriber 1
                      │  Broker  │
Sensor B ──publish──→ │ (Mosquitto)│ ──→ Subscriber 2
                      └──────────┘

Example: Temperature Sensor
#

Publishing a temperature reading:

import paho.mqtt.client as mqtt
import json

client = mqtt.Client()
client.connect("broker.local", 1883)

payload = json.dumps({
    "temperature": 72.5,
    "unit": "celsius",
    "timestamp": "2026-03-05T10:30:00Z"
})

client.publish("factory/line1/machine3/temperature", payload, qos=1)

Subscribing to all sensors on a production line:

def on_message(client, userdata, msg):
    data = json.loads(msg.payload)
    print(f"{msg.topic}: {data['temperature']}°C")

client.subscribe("factory/line1/+/temperature")
client.on_message = on_message
client.loop_forever()

Strengths
#

Extremely lightweight — runs on microcontrollers with 32KB RAM
QoS levels (0, 1, 2) for delivery guarantees
Retained messages — new subscribers get the last known value
Last Will and Testament — automatic offline detection
Massive ecosystem: Mosquitto, EMQX, HiveMQ, VerneMQ

Weaknesses
#

No data model — payload is raw bytes, you decide the format (JSON, Protobuf, etc.)
No topic namespace standard — every company invents their own topic tree
No request/reply — you have to build it yourself with correlated topics
Broker is a single point of failure — clustering requires commercial brokers
No built-in persistence — messages are gone once delivered

When to Use MQTT
#

Constrained edge devices (ESP32, Raspberry Pi)
Simple telemetry: send sensor values to a cloud platform
Brownfield integration where devices already speak MQTT
When you need maximum device compatibility

Sparkplug B — MQTT with an Industrial Brain
#

Sparkplug B is not a separate protocol — it’s a specification on top of MQTT that solves MQTT’s biggest weaknesses for industrial use: no data model, no state management, and no standardized topic namespace.

How It Differs from Plain MQTT
#

Plain MQTT:
  Topic:   factory/line1/machine3/temperature
  Payload: {"value": 72.5}  ← you decide the format

Sparkplug B:
  Topic:   spBv1.0/FactoryGroup/DDATA/Line1/Machine3
  Payload: Protobuf-encoded metrics with types, timestamps, and aliases

The Birth/Death Certificate Model
#

Sparkplug introduces NBIRTH (Node Birth), DBIRTH (Device Birth), NDEATH, and DDEATH messages. This creates a state-aware system:

Edge Node connects    → publishes NBIRTH (declares all metrics)
Device comes online   → publishes DBIRTH (declares device metrics)
Data changes          → publishes DDATA (only changed metrics)
Device goes offline   → broker publishes DDEATH (via LWT)
Edge Node disconnects → broker publishes NDEATH (via LWT)

Example: Sparkplug Metric
#

from sparkplug_b import MetricDataType, Payload

payload = Payload()
metric = payload.metrics.add()
metric.name = "Temperature"
metric.datatype = MetricDataType.Float
metric.float_value = 72.5
metric.timestamp = int(time.time() * 1000)

# Alias-based updates — after BIRTH, only send alias + value
metric_update = payload.metrics.add()
metric_update.alias = 1  # "Temperature" was alias 1 in BIRTH
metric_update.float_value = 73.1

Topic Namespace
#

Sparkplug defines a strict topic structure:

spBv1.0/{group_id}/{message_type}/{edge_node_id}/{device_id}

Examples:
  spBv1.0/Plant1/NBIRTH/Gateway1        → Node birth
  spBv1.0/Plant1/DBIRTH/Gateway1/PLC1   → Device birth
  spBv1.0/Plant1/DDATA/Gateway1/PLC1    → Device data
  spBv1.0/Plant1/DCMD/Gateway1/PLC1     → Device command

Strengths
#

Standardized data model — types, timestamps, metadata for every metric
State awareness — always know which devices are online and what they report
Bandwidth efficient — alias-based encoding, only changed values sent
Interoperable — any Sparkplug-compliant client understands any Sparkplug publisher
SCADA integration — Ignition, Inductive Automation, and others natively support it

Weaknesses
#

Still relies on MQTT broker — inherits broker limitations
Protobuf encoding — harder to debug than JSON (need decoding tools)
More complex than plain MQTT — birth/death lifecycle adds overhead
Limited ecosystem compared to raw MQTT

When to Use Sparkplug B
#

SCADA systems where you need a standardized namespace
Multi-vendor environments where plain MQTT becomes chaotic
When a central application (like Ignition) needs to auto-discover devices
Brownfield MQTT infrastructure where you want to add structure

NATS — The Cloud-Native Speed Demon
#

NATS comes from the cloud-native world (it’s a CNCF project) but is increasingly used in industrial IoT for its raw speed, operational simplicity, and built-in persistence via JetStream.

Architecture
#

Unlike MQTT’s broker model, NATS uses a mesh of servers that form a cluster. There’s no single point of failure.

                    ┌──────────┐
Edge Device 1 ───→ │  NATS-1  │ ←─── Cloud Service A
                    └────┬─────┘
                         │ cluster
                    ┌────┴─────┐
Edge Device 2 ───→ │  NATS-2  │ ←─── Cloud Service B
                    └────┬─────┘
                         │ cluster
                    ┌────┴─────┐
Edge Device 3 ───→ │  NATS-3  │ ←─── Dashboard
                    └──────────┘

Example: Pub/Sub
#

nc, _ := nats.Connect("nats://nats.local:4222")

// Publish
nc.Publish("factory.line1.machine3.temperature",
    []byte(`{"value": 72.5, "unit": "celsius"}`))

// Subscribe with wildcards
nc.Subscribe("factory.line1.*.temperature", func(msg *nats.Msg) {
    fmt.Printf("Received: %s\n", string(msg.Data))
})

Example: Request/Reply (built-in)
#

Something MQTT can’t do natively:

// Service: responds to recipe requests
nc.Subscribe("recipe.get", func(msg *nats.Msg) {
    recipe := loadRecipe(string(msg.Data))
    msg.Respond([]byte(recipe))
})

// Client: request with timeout
reply, err := nc.Request("recipe.get", []byte("product-42"), 2*time.Second)
fmt.Println(string(reply.Data))

JetStream — Persistent Streaming
#

JetStream adds persistence, replay, and exactly-once delivery:

js, _ := nc.JetStream()

// Create a stream that retains messages
js.AddStream(&nats.StreamConfig{
    Name:      "SENSORS",
    Subjects:  []string{"factory.>"},
    Retention: nats.LimitsPolicy,
    MaxAge:    24 * time.Hour,
})

// Publish (persisted)
js.Publish("factory.line1.machine3.temperature",
    []byte(`{"value": 72.5}`))

// Durable consumer — survives restarts
sub, _ := js.PullSubscribe("factory.line1.>", "analytics-consumer")
msgs, _ := sub.Fetch(10)

Key-Value Store
#

NATS includes a distributed key-value store — no need for Redis or etcd:

kv, _ := js.CreateKeyValue(&nats.KeyValueConfig{
    Bucket: "machine-config",
})

kv.Put("machine3.setpoint", []byte("72.5"))
entry, _ := kv.Get("machine3.setpoint")
fmt.Println(string(entry.Value()))

// Watch for changes in real-time
watcher, _ := kv.Watch("machine3.*")
for update := range watcher.Updates() {
    fmt.Printf("%s = %s\n", update.Key(), string(update.Value()))
}

Strengths
#

Blazing fast — 10M+ messages/second
Request/Reply — native, not hacked on top
JetStream — persistence, replay, exactly-once delivery built-in
Key-Value Store — distributed config without external dependencies
Clustering — true HA with no single point of failure
Leaf Nodes — edge NATS servers that sync with cloud clusters
Embedded server — run NATS inside your application

Weaknesses
#

No data model — same as MQTT, payload is raw bytes
No OT industry standard — not recognized by automation vendors (yet)
Less device support — no ESP32 or microcontroller clients
Less tooling — fewer GUI management tools than MQTT

When to Use NATS
#

High-throughput data pipelines (vibration data, high-frequency sensors)
Edge-to-cloud mesh architectures with leaf nodes
Microservice communication on the edge
When you need request/reply patterns
When you want persistence without external databases

OPC-UA — The Industrial Standard
#

OPC-UA is the established standard in factory automation. Every major PLC vendor supports it: Siemens, Beckhoff, Allen-Bradley, ABB, B&R, Mitsubishi. If you work in OT, you can’t avoid it.

Information Model
#

OPC-UA’s killer feature is its rich information model. It’s not just values — it’s a browsable tree of objects with types, relationships, and metadata:

Root
├── Objects
│   ├── Server (diagnostics, capabilities)
│   └── Factory
│       ├── Line1
│       │   ├── Machine3
│       │   │   ├── Temperature (Float, °C, range: 0-200)
│       │   │   ├── Speed (Int32, RPM, range: 0-3000)
│       │   │   ├── Status (Enum: Running, Stopped, Error)
│       │   │   └── Methods
│       │   │       ├── Start()
│       │   │       └── Stop()
│       │   └── Machine4
│       └── Line2
└── Types
    └── MachineType (defines the structure above)

Example: Reading Values
#

from opcua import Client

client = Client("opc.tcp://plc.local:4840")
client.connect()

# Browse the address space
root = client.get_root_node()
objects = client.get_objects_node()

# Read a specific node
temp_node = client.get_node("ns=2;s=Machine3.Temperature")
value = temp_node.get_value()
data_type = temp_node.get_data_type_as_variant_type()
print(f"Temperature: {value} (type: {data_type})")

# Read with full metadata
data_value = temp_node.get_data_value()
print(f"Value: {data_value.Value.Value}")
print(f"Status: {data_value.StatusCode}")
print(f"Timestamp: {data_value.SourceTimestamp}")

Example: Subscriptions
#

class SubHandler:
    def datachange_notification(self, node, val, data):
        print(f"{node} changed to {val}")

handler = SubHandler()
subscription = client.create_subscription(500, handler)  # 500ms interval

# Monitor multiple nodes
nodes = [
    client.get_node("ns=2;s=Machine3.Temperature"),
    client.get_node("ns=2;s=Machine3.Speed"),
    client.get_node("ns=2;s=Machine3.Status"),
]
subscription.subscribe_data_change(nodes)

Example: Calling Methods
#

# Call a method on the PLC
machine = client.get_node("ns=2;s=Machine3")
method = client.get_node("ns=2;s=Machine3.Start")

# Start the machine with parameters
result = machine.call_method(method, 1500)  # target speed: 1500 RPM
print(f"Method result: {result}")

Strengths
#

Rich information model — self-describing, browsable, typed
Industry standard — every PLC vendor supports it
Security — X.509 certificates, user authentication, encrypted transport
Methods — call functions on PLCs remotely
Historical data — built-in historian access
Discovery — servers announce themselves on the network
Companion specifications — standardized models for robotics, CNC, packaging, etc.

Weaknesses
#

Complex — the specification is 1,200+ pages
Slower — higher latency than MQTT or NATS
Heavy — not suitable for constrained devices
Client/Server — no native pub/sub across systems (OPC-UA Pub/Sub exists but adoption is low)
Licensing — some SDKs are expensive

When to Use OPC-UA
#

PLC and SCADA integration (this is what it’s built for)
Multi-vendor automation (Siemens + Beckhoff + ABB in one factory)
When you need typed, self-describing data with browse capability
Compliance-driven environments (Industrie 4.0, RAMI 4.0)

Decision Matrix
#

                    ┌─────────────────────────────────────────────┐
                    │        What's your primary use case?        │
                    └──────────────────┬──────────────────────────┘
                                       │
                    ┌──────────────────┼──────────────────┐
                    ▼                  ▼                  ▼
             Sensor Telemetry    PLC Integration    High-Throughput
             (edge devices)      (automation)       Data Pipeline
                    │                  │                  │
              ┌─────┴─────┐           │            ┌─────┴─────┐
              ▼           ▼           ▼            ▼           ▼
          Simple?    Need SCADA    OPC-UA       Need        Cloud-
              │      standard?        │        Persistence?  native?
              │           │           │            │           │
          ┌───┴──┐   ┌───┴──┐        │       ┌───┴──┐   ┌───┴──┐
          ▼      ▼   ▼      ▼        │       ▼      ▼   ▼      ▼
        MQTT  Spark  Spark  MQTT     Done    NATS   MQTT  NATS  NATS
              plug   plug                   (JS)   (+DB)

Combining Protocols
#

In practice, most industrial architectures use multiple protocols. Here’s a pattern I use frequently:

┌─────────┐  OPC-UA   ┌───────────┐  NATS    ┌───────────┐
│ Siemens ├──────────→│           ├─────────→│   Cloud   │
│   PLC   │           │  Node-RED │          │ Analytics │
└─────────┘           │  (Edge)   │  MQTT    ┌───────────┐
┌─────────┐  MQTT     │           ├─────────→│ Dashboard │
│  ESP32  ├──────────→│           │          └───────────┘
│ Sensors │           └───────────┘
└─────────┘

OPC-UA talks to the PLCs (typed data, methods, browse)
MQTT collects data from constrained sensors
NATS moves everything to the cloud (fast, persistent, scalable)

The key insight: protocols are tools, not religions. Use each where it excels.

Conclusion
#

Choose…	When…
MQTT	You need maximum device compatibility and simplicity
Sparkplug B	You have MQTT but need structure, state management, and SCADA integration
NATS	You need speed, request/reply, persistence, and cloud-native architecture
OPC-UA	You’re integrating with PLCs and need typed, self-describing industrial data

There’s no single “best” protocol. The best industrial IoT architecture uses the right protocol at each layer — and Node-RED makes it easy to bridge between all of them.

IIoT - This article is part of a series.

Part : i3x — The Open Manufacturing API That Breaks Data Silos

Part : This Article

The Quick Overview#

MQTT — The Universal Connector#

How It Works#

Example: Temperature Sensor#

Strengths#

Weaknesses#

When to Use MQTT#

Sparkplug B — MQTT with an Industrial Brain#

How It Differs from Plain MQTT#

The Birth/Death Certificate Model#

Example: Sparkplug Metric#

Topic Namespace#

Strengths#

Weaknesses#

When to Use Sparkplug B#

NATS — The Cloud-Native Speed Demon#

Architecture#

Example: Pub/Sub#

Example: Request/Reply (built-in)#

JetStream — Persistent Streaming#

Key-Value Store#

Strengths#

Weaknesses#

When to Use NATS#

OPC-UA — The Industrial Standard#

Information Model#

Example: Reading Values#

Example: Subscriptions#

Example: Calling Methods#

Strengths#

Weaknesses#

When to Use OPC-UA#

Decision Matrix#

Combining Protocols#

Conclusion#

Related

The Quick Overview
#

MQTT — The Universal Connector
#

How It Works
#

Example: Temperature Sensor
#

Strengths
#

Weaknesses
#

When to Use MQTT
#

Sparkplug B — MQTT with an Industrial Brain
#

How It Differs from Plain MQTT
#

The Birth/Death Certificate Model
#

Example: Sparkplug Metric
#

Topic Namespace
#

Strengths
#

Weaknesses
#

When to Use Sparkplug B
#

NATS — The Cloud-Native Speed Demon
#

Architecture
#

Example: Pub/Sub
#

Example: Request/Reply (built-in)
#

JetStream — Persistent Streaming
#

Key-Value Store
#

Strengths
#

Weaknesses
#

When to Use NATS
#

OPC-UA — The Industrial Standard
#

Information Model
#

Example: Reading Values
#

Example: Subscriptions
#

Example: Calling Methods
#

Strengths
#

Weaknesses
#

When to Use OPC-UA
#

Decision Matrix
#

Combining Protocols
#

Conclusion
#
