MQTT got us far. Every IIoT project I’ve worked on started with Mosquitto, some topics, and QoS 1. It works — until you need message replay, exactly-once delivery, or synchronizing configuration across 30 factory sites. Then you start bolting on Kafka for persistence, Redis for key-value state, and a custom sync mechanism for edge-to-cloud. Three systems to operate, three failure modes to debug at 2 AM.

NATS replaces all three. It’s a single binary that handles pub/sub messaging, persistent streams (JetStream), key-value stores, and edge-to-cloud synchronization (leaf nodes) — all with built-in clustering and zero external dependencies.

This post walks through a complete NATS-based architecture for industrial IoT.

Architecture Overview
#

                            ┌──────────────────────┐
                            │    Cloud NATS Cluster │
                            │  ┌────┐ ┌────┐ ┌────┐│
                            │  │ N1 │ │ N2 │ │ N3 ││
                            │  └──┬─┘ └──┬─┘ └──┬─┘│
                            │     └──────┼──────┘  │
                            │            │         │
                            │    JetStream Streams  │
                            │    KV Stores          │
                            │    Object Store       │
                            └────────┬─────────────┘
                                     │
                          TLS / WebSocket
                          (NAT-friendly)
                    ┌────────────┼────────────┐
                    │            │            │
              ┌─────┴─────┐┌────┴──────┐┌────┴──────┐
              │  Factory A ││ Factory B ││ Factory C │
              │  Leaf Node ││ Leaf Node ││ Leaf Node │
              │  ┌───────┐ ││ ┌───────┐ ││ ┌───────┐ │
              │  │ NATS  │ ││ │ NATS  │ ││ │ NATS  │ │
              │  │ Edge  │ ││ │ Edge  │ ││ │ Edge  │ │
              │  └───┬───┘ ││ └───┬───┘ ││ └───┬───┘ │
              │      │     ││     │     ││     │     │
              │  ┌───┴───┐ ││ ┌───┴───┐ ││ ┌───┴───┐ │
              │  │Sensors│ ││ │Sensors│ ││ │Sensors│ │
              │  │PLCs   │ ││ │PLCs   │ ││ │PLCs   │ │
              │  │Gateways│││ │Gateways│││ │Gateways││
              │  └───────┘ ││ └───────┘ ││ └───────┘ │
              └───────────┘└───────────┘└───────────┘

Each factory runs a local NATS server as a leaf node. Sensors and PLCs publish to the local server with sub-millisecond latency. The leaf node selectively forwards messages to the cloud cluster over a single TLS connection — NAT-friendly, firewall-friendly, resumable on disconnect.

Why NATS Over MQTT + Kafka?
#

Capability	MQTT + Kafka	NATS (with JetStream)
Pub/Sub	MQTT broker	NATS core
Persistent streams	Kafka	JetStream
Key-value store	Redis / etcd	NATS KV
Edge-to-cloud sync	Custom bridge	Leaf nodes (built-in)
Clustering	MQTT: limited, Kafka: ZooKeeper/KRaft	Built-in RAFT
Message replay	Kafka (complex consumer groups)	JetStream (simple)
Exactly-once	Kafka (idempotent producer)	JetStream (dedup window)
Dependencies	3 systems (MQTT, Kafka, Redis)	1 binary
Memory footprint	Kafka: 1+ GB, MQTT: 50 MB, Redis: 100 MB	50–200 MB total
Ops complexity	High (3 systems to monitor, upgrade, backup)	Low (1 system)

The operational argument is the strongest: running and monitoring one system is fundamentally simpler than running three.

Subject Naming Convention
#

A well-designed subject hierarchy is critical. For industrial IoT, I use this pattern:

{org}.{site}.{area}.{line}.{machine}.{sensor}.{metric}

Examples:
  acme.munich.hall-a.line-1.cnc-001.spindle.vibration.rms
  acme.munich.hall-a.line-1.cnc-001.spindle.vibration.spectrum
  acme.munich.hall-a.line-1.cnc-001.motor.current
  acme.munich.hall-a.line-1.cnc-001.coolant.temperature
  acme.munich.hall-a.line-1.cnc-001.status.operational_state

Wildcards
#

NATS supports two wildcards that make this hierarchy powerful:

acme.munich.hall-a.line-1.*.spindle.vibration.rms
  → All machines on line 1, spindle vibration RMS

acme.munich.hall-a.>
  → Everything from Hall A (all lines, machines, sensors)

acme.*.*.*.*.*.temperature
  → All temperature readings across all sites

The * matches a single token, > matches one or more tokens (only at the end). This lets cloud analytics subscribe to broad patterns while edge devices publish to specific subjects.

Reserved Subjects
#

_EVENTS.>                  → NATS system events
$JS.>                      → JetStream internal
_KV.>                      → Key-value store internal

acme.*.config.>            → Machine configuration (KV-backed)
acme.*.alert.>             → Alert messages (priority routing)
acme.*.command.>           → Commands from cloud to edge
acme.*.model.>             → ML model updates

JetStream: Persistent Streams
#

Core NATS is fire-and-forget — if nobody’s listening, the message is lost. JetStream adds persistence and replay, turning NATS into an event log.

Stream Configuration
#

{
  "name": "TELEMETRY",
  "subjects": ["acme.*.*.*.*.*.vibration.>", "acme.*.*.*.*.*.temperature"],
  "retention": "limits",
  "max_bytes": 10737418240,
  "max_age": 604800000000000,
  "storage": "file",
  "num_replicas": 3,
  "discard": "old",
  "duplicate_window": 120000000000,
  "compression": "s2"
}

This stream captures all vibration and temperature data, retains it for 7 days (or until 10 GB is reached), deduplicates messages within a 2-minute window, and replicates across 3 nodes with S2 compression.

Consumer Types
#

Consumer Type	Use Case	Behavior
Push	Real-time dashboard	NATS delivers messages as they arrive
Pull	Batch analytics	Application pulls N messages at a time
Durable	Critical processing	Survives restarts, resumes from last ack
Ephemeral	Monitoring, debugging	Disappears when client disconnects

Go Producer Example
#

package main

import (
    "encoding/json"
    "fmt"
    "time"

    "github.com/nats-io/nats.go"
    "github.com/nats-io/nats.go/jetstream"
)

type TelemetryMessage struct {
    MachineID string    `json:"machine_id"`
    Sensor    string    `json:"sensor"`
    Value     float64   `json:"value"`
    Unit      string    `json:"unit"`
    Timestamp time.Time `json:"timestamp"`
    Quality   string    `json:"quality"`
}

func main() {
    nc, err := nats.Connect(
        "nats://localhost:4222",
        nats.RetryOnFailedConnect(true),
        nats.MaxReconnects(-1),
        nats.ReconnectWait(2*time.Second),
    )
    if err != nil {
        panic(err)
    }
    defer nc.Close()

    js, err := jetstream.New(nc)
    if err != nil {
        panic(err)
    }

    msg := TelemetryMessage{
        MachineID: "cnc-001",
        Sensor:    "spindle",
        Value:     2.45,
        Unit:      "mm/s",
        Timestamp: time.Now().UTC(),
        Quality:   "good",
    }

    data, _ := json.Marshal(msg)
    subject := fmt.Sprintf("acme.munich.hall-a.line-1.%s.spindle.vibration.rms",
        msg.MachineID)

    ack, err := js.Publish(subject, data,
        jetstream.WithMsgID(fmt.Sprintf("%s-%d", msg.MachineID, msg.Timestamp.UnixNano())),
    )
    if err != nil {
        panic(err)
    }
    fmt.Printf("Published seq=%d stream=%s\n", ack.Sequence, ack.Stream)
}

Python Consumer Example
#

import asyncio
import json
import nats
from nats.js.api import ConsumerConfig, DeliverPolicy

async def main():
    nc = await nats.connect("nats://localhost:4222")
    js = nc.jetstream()

    config = ConsumerConfig(
        durable_name="analytics-consumer",
        deliver_policy=DeliverPolicy.LAST_PER_SUBJECT,
        filter_subject="acme.munich.hall-a.>",
        ack_wait=30,
        max_deliver=3,
    )

    sub = await js.subscribe(
        "acme.munich.hall-a.>",
        stream="TELEMETRY",
        config=config,
    )

    async for msg in sub.messages:
        data = json.loads(msg.data.decode())
        print(f"{msg.subject}: {data['value']} {data['unit']}")
        await msg.ack()

asyncio.run(main())

KV Store: Machine Configuration
#

NATS KV is a key-value store built on JetStream. Perfect for storing machine configuration that needs to sync between edge and cloud:

import asyncio
import json
import nats

async def main():
    nc = await nats.connect("nats://localhost:4222")
    js = nc.jetstream()

    kv = await js.create_key_value(
        name="MACHINE_CONFIG",
        history=5,
        ttl=0,
    )

    config = {
        "machine_id": "cnc-001",
        "vibration": {
            "sample_rate": 25600,
            "fft_size": 1024,
            "alert_threshold_rms": 4.5,
            "bearing_type": "6205",
        },
        "maintenance": {
            "last_service": "2026-02-15",
            "next_scheduled": "2026-04-15",
            "operating_hours": 4280,
        },
    }

    await kv.put("cnc-001", json.dumps(config).encode())

    entry = await kv.get("cnc-001")
    data = json.loads(entry.value.decode())
    print(f"Machine: {data['machine_id']}, Hours: {data['maintenance']['operating_hours']}")

    watcher = await kv.watch("cnc-*")
    async for update in watcher:
        if update is None:
            continue
        print(f"Config changed: {update.key} rev={update.revision}")

asyncio.run(main())

When a maintenance engineer updates machine configuration in the cloud dashboard, the KV change propagates to the edge leaf node automatically. The edge Node-RED flow watches for KV changes and reconfigures the monitoring pipeline on the fly.

Leaf Nodes: Edge-to-Cloud Sync
#

Leaf nodes are the killer feature for industrial IoT. A leaf node is a local NATS server that connects to a remote cluster and selectively synchronizes subjects:

Edge NATS Configuration
#

# /etc/nats/edge-server.conf

server_name: factory-munich-edge

listen: 0.0.0.0:4222

jetstream {
    store_dir: /data/nats/jetstream
    max_mem: 256MB
    max_file: 5GB
}

leafnodes {
    remotes [
        {
            url: "tls://cloud-nats.company.com:7422"
            credentials: "/etc/nats/creds/factory-munich.creds"

            # Only forward these subjects to the cloud
            deny_imports: ["_INBOX.>"]
            deny_exports: []
        }
    ]
}

authorization {
    users: [
        { user: "node-red", password: "$NODERED_PASS",
          permissions: {
            publish: ["acme.munich.>"]
            subscribe: ["acme.munich.>", "acme.*.config.>", "acme.*.command.>"]
          }
        },
        { user: "plc-gateway", password: "$PLC_PASS",
          permissions: {
            publish: ["acme.munich.hall-a.>"]
            subscribe: []
          }
        }
    ]
}

# Store-and-forward when cloud connection drops
leafnodes {
    reconnect_delay: "5s"
}

What Happens When the Network Drops?
#

This is where NATS shines compared to MQTT bridges:

Normal operation:
  [Edge] ──publish──→ [Local NATS] ──leaf──→ [Cloud NATS] ──→ [Analytics]

Network drops:
  [Edge] ──publish──→ [Local NATS] ──X──  [Cloud NATS]
                        │
                        └── JetStream stores messages locally
                            (up to 5 GB / configured limit)

Network recovers:
  [Edge]               [Local NATS] ──leaf──→ [Cloud NATS] ──→ [Analytics]
                        │                        │
                        └── Replays buffered ────┘
                            messages in order

Local edge applications (Node-RED dashboards, local alerts) continue working because they subscribe to the local NATS server. The cloud just receives data late — but in order and without gaps.

Docker Compose: Local Development Cluster
#

Test the full architecture locally:

services:
  nats-cloud-1:
    image: nats:2.10-alpine
    command: >
      --name cloud-1
      --cluster_name cloud
      --cluster nats://0.0.0.0:6222
      --routes nats://nats-cloud-2:6222,nats://nats-cloud-3:6222
      --js
      --sd /data
      --leafnodes nats://0.0.0.0:7422
    volumes:
      - cloud1-data:/data
    ports:
      - "4222:4222"
      - "8222:8222"

  nats-cloud-2:
    image: nats:2.10-alpine
    command: >
      --name cloud-2
      --cluster_name cloud
      --cluster nats://0.0.0.0:6222
      --routes nats://nats-cloud-1:6222,nats://nats-cloud-3:6222
      --js
      --sd /data
    volumes:
      - cloud2-data:/data

  nats-cloud-3:
    image: nats:2.10-alpine
    command: >
      --name cloud-3
      --cluster_name cloud
      --cluster nats://0.0.0.0:6222
      --routes nats://nats-cloud-1:6222,nats://nats-cloud-2:6222
      --js
      --sd /data
    volumes:
      - cloud3-data:/data

  nats-edge-munich:
    image: nats:2.10-alpine
    command: >
      --name edge-munich
      --js
      --sd /data
      --leafnodes "nats://nats-cloud-1:7422"
    volumes:
      - edge-munich-data:/data
    ports:
      - "4223:4222"
    depends_on:
      - nats-cloud-1

  nats-edge-berlin:
    image: nats:2.10-alpine
    command: >
      --name edge-berlin
      --js
      --sd /data
      --leafnodes "nats://nats-cloud-1:7422"
    volumes:
      - edge-berlin-data:/data
    ports:
      - "4224:4222"
    depends_on:
      - nats-cloud-1

  node-red:
    image: nodered/node-red:latest
    ports:
      - "1880:1880"
    volumes:
      - nodered-data:/data
    depends_on:
      - nats-edge-munich
    environment:
      - NATS_URL=nats://nats-edge-munich:4222

volumes:
  cloud1-data:
  cloud2-data:
  cloud3-data:
  edge-munich-data:
  edge-berlin-data:
  nodered-data:

docker compose up -d

# Verify cluster health
docker exec -it $(docker compose ps -q nats-cloud-1) \
  nats server list

# Create the telemetry stream
docker exec -it $(docker compose ps -q nats-cloud-1) \
  nats stream add TELEMETRY \
    --subjects "acme.>" \
    --retention limits \
    --max-bytes 1GB \
    --max-age 7d \
    --storage file \
    --replicas 3 \
    --compression s2

# Publish from "edge munich" and consume from "cloud"
docker exec -it $(docker compose ps -q nats-edge-munich) \
  nats pub acme.munich.hall-a.line-1.cnc-001.spindle.vibration.rms \
    '{"value": 2.45, "unit": "mm/s"}'

docker exec -it $(docker compose ps -q nats-cloud-1) \
  nats sub "acme.munich.>"

Bandwidth Calculations
#

Industrial telemetry can generate significant data volumes. Plan your leaf node connections accordingly:

Per-Machine Data Budget
#

Data Type	Message Size	Frequency	Bandwidth
Vibration RMS	100 bytes	1/sec	100 B/s
Vibration spectrum (512 bins)	4 KB	1/5 sec	800 B/s
Temperature	80 bytes	1/10 sec	8 B/s
Current draw	80 bytes	1/sec	80 B/s
Status change	120 bytes	Event-driven (~1/min)	2 B/s
Total per machine			~990 B/s ≈ 1 KB/s

Factory Scale
#

Scale	Machines	Raw Bandwidth	With Compression (S2)
Small line	10	10 KB/s	~3 KB/s
Large line	50	50 KB/s	~15 KB/s
Single factory	200	200 KB/s	~60 KB/s
10 factories	2,000	2 MB/s	~600 KB/s

Even 10 factories with 200 machines each only generate ~600 KB/s to the cloud cluster — well within a single 4G cellular connection (typically 5–50 Mbps). NATS S2 compression and JetStream deduplication keep the overhead minimal.

Edge Buffer Sizing
#

How long can the edge operate offline? With a 5 GB JetStream store and 200 machines at 200 KB/s compressed:

5 GB / 60 KB/s ≈ 83,333 seconds ≈ 23 hours

Twenty-three hours of offline buffering. Enough to survive a full business day of internet outage.

NATS in Node-RED
#

Use the node-red-contrib-nats-streaming or a custom NATS node to integrate:

┌──────────┐    ┌──────────────┐    ┌──────────┐    ┌──────────┐
│ OPC-UA   ├───→│ Transform    ├───→│ NATS     ├───→│ Local    │
│ Client   │    │ to JSON      │    │ Publish  │    │ NATS     │
│          │    │              │    │          │    │ Server   │
└──────────┘    └──────────────┘    └──────────┘    └────┬─────┘
                                                         │
                                                    Leaf Node
                                                         │
                                                    ┌────┴─────┐
                                                    │ Cloud    │
                                                    │ NATS     │
                                                    │ Cluster  │
                                                    └──────────┘

Node-RED function node for NATS subject construction:

const site = flow.get("site") || "munich";
const area = msg.payload.area || "hall-a";
const line = msg.payload.line || "line-1";
const machine = msg.payload.machine_id;
const sensor = msg.payload.sensor_type;
const metric = msg.payload.metric;

msg.topic = `acme.${site}.${area}.${line}.${machine}.${sensor}.${metric}`;

msg.payload = {
    value: msg.payload.value,
    unit: msg.payload.unit,
    timestamp: new Date().toISOString(),
    quality: msg.payload.quality || "good",
};

return msg;

Topology Comparison
#

Three ways to connect edge to cloud — and when to use each:

Star Topology (Leaf Nodes):          Mesh Topology:

     ┌─Edge A─┐                       ┌─Edge A─┐
     └───┬────┘                        └───┬────┘
         │                                 │╲
     ┌───┴────┐                        ┌───┴────┐
     │ Cloud  │                        │ Cloud  │
     └───┬────┘                        └───┬────┘
         │                                 │╱
     ┌───┴────┐                        ┌───┴────┐
     └─Edge B─┘                        └─Edge B─┘

Best for: Most IIoT              Best for: Edge-to-edge
  (simple, scalable)               communication needed


Gateway Tree:

     ┌─Sensor─┐   ┌─Sensor─┐
     └───┬────┘   └───┬────┘
         └─────┬──────┘
          ┌────┴─────┐
          │ Line GW  │
          └────┬─────┘
          ┌────┴─────┐
          │ Factory  │
          │ Edge     │
          └────┬─────┘
          ┌────┴─────┐
          │  Cloud   │
          └──────────┘

Best for: Large factories
  with many sensors per line

For most industrial IoT deployments, the star topology with leaf nodes is the right choice. It’s simple, scales linearly, and the cloud cluster never becomes a single point of failure for local operations.

Conclusion
#

NATS simplifies the IIoT messaging stack from three systems (MQTT + Kafka + Redis) down to one. Leaf nodes solve the edge-to-cloud synchronization problem that has plagued industrial IoT architectures for years — with automatic store-and-forward, subject-based filtering, and zero custom bridge code.

The subject naming convention is worth spending time on. Get it right at the start, and every downstream system — from dashboards to ML pipelines to alerting rules — becomes a simple wildcard subscription. Get it wrong, and you’re refactoring message routing across 30 factories.

Start with the docker-compose setup above. Publish some test data from the edge. Subscribe from the cloud. Kill the network connection and watch the messages buffer. Bring it back and watch them replay. That demo alone is more convincing than any architecture slide deck.

IIoT - This article is part of a series.

Part : This Article

Part : Running ML Models at the Edge with ONNX and Node-RED

Part : Predictive Maintenance with Node-RED — From Vibration Sensor to Health Score

Part : i3x — The Open Manufacturing API That Breaks Data Silos

Part : MQTT vs Sparkplug B vs NATS vs OPC-UA — Which Protocol for Industrial IoT?

Architecture Overview#

Why NATS Over MQTT + Kafka?#

Subject Naming Convention#

Wildcards#

Reserved Subjects#

JetStream: Persistent Streams#

Stream Configuration#

Consumer Types#

Go Producer Example#

Python Consumer Example#

KV Store: Machine Configuration#

Leaf Nodes: Edge-to-Cloud Sync#

Edge NATS Configuration#

What Happens When the Network Drops?#

Docker Compose: Local Development Cluster#

Bandwidth Calculations#

Per-Machine Data Budget#

Factory Scale#

Edge Buffer Sizing#

NATS in Node-RED#

Topology Comparison#

Conclusion#

Related
