Kafka Suite

The Problem

#

Apache Kafka is the de-facto standard for high-throughput event streaming in enterprise and industrial data pipelines — but getting Node-RED to talk to Kafka properly means picking a client library, wiring up Schema Registry, handling SASL/mTLS for managed services, and tuning consumer groups by hand. Existing Node-RED Kafka nodes cover the basics but fall short on schema handling, authentication variety, and production-grade connection management.

The Solution

#

A comprehensive Node-RED integration for Apache Kafka with producer/consumer/admin nodes, Confluent-compatible Schema Registry support, and a choice of two backends — pure-JavaScript kafkajs or the native librdkafka binding — selectable per broker. Managed-service presets make connecting to Confluent Cloud, AWS MSK, Azure Event Hubs, Aiven, and Redpanda a one-click affair.

blanpa/node-red-contrib-kafka-suite

JavaScript

0

0

Producer

#

• Single & batch messaging — publish one message or many in a single call
• Key-based partitioning — deterministic routing via message keys
• Headers & compression — GZIP, Snappy, LZ4, ZSTD
• Delivery confirmation — success output emits msg.kafka metadata (topic, partition, offset)

Consumer

#

• Consumer groups — automatic load balancing across instances
• Offset management — earliest/latest/explicit, commit strategies
• Pause/resume controls — backpressure without disconnecting
• Flexible payload formats — JSON, UTF-8, or raw Buffer
• Concurrent partition consumption — parallel processing per topic

Admin Operations

#

Unified msg.action interface for:

• Topic lifecycle — create, delete, list, describe, alter configs
• Cluster inspection — brokers, controllers, metadata
• Consumer group administration — list, describe, delete, reset offsets
• Offset manipulation — seek to timestamp, earliest, latest

Schema Registry

#

Confluent-compatible wire format for structured data:

• Avro, JSON Schema, Protobuf — encode and decode transparently
• Automatic schema registration — optional, per producer
• Subject compatibility checking — catches breaking changes at publish time

Dual-Backend Architecture

#

Backend is selected per broker config — mix and match in the same flow.

Managed Service Presets

#

Built-in one-click configurations for:

• Confluent Cloud — SASL/PLAIN
• AWS MSK — IAM and SCRAM variants
• Azure Event Hubs — Kafka protocol endpoint
• Aiven — mutual TLS
• Redpanda — self-hosted or cloud
• Self-hosted clusters — full custom SASL/TLS

Authentication & Security

#

• SASL — PLAIN, SCRAM-SHA-256/512, OAUTHBEARER
• Mutual TLS — drag-and-drop certificates
• Unauthenticated — for dev/test clusters
• Connection pooling — shared connection per broker config with ref-counted lifecycle and automatic reconnection
