NATS Messaging Suite

The Problem

#

Industrial IoT systems need reliable, low-latency messaging between machines, edge devices, and cloud services. Traditional MQTT brokers work for simple pub/sub, but fall short when you need persistent message streams, exactly-once delivery, or distributed key-value storage. Building custom messaging infrastructure is complex and error-prone.

The Solution

#

A comprehensive Node-RED integration for NATS — the cloud-native messaging system built for performance. This module brings the full power of NATS into Node-RED’s visual programming environment: core messaging, persistent streaming via JetStream, and key-value storage — all without writing code.

Architecture

#

The 8 nodes cover the three NATS surfaces — core messaging, persistent JetStream, and the KV store — and can run against an external cluster or an embedded server right inside Node-RED:

flowchart LR
    subgraph NR["Node-RED Flow"]
        PUB["nats-suite-publish
(pub · request/reply)"]
        SUB["nats-suite-subscribe"]
        JSP["nats-suite-stream-publisher"]
        JSC["nats-suite-stream-consumer"]
        KVG["nats-suite-kv-get"]
        KVP["nats-suite-kv-put"]
        SRVM["nats-suite-server-manager
(embedded)"]
    end
    CFG["nats-suite-server
auth · TLS · cluster failover"]
    CORE["Core NATS
pub/sub · req/rep · queue groups"]
    JSE["JetStream
streams · consumers · replay"]
    KVE["KV Store
watch · history · TTL"]
    MQTT["MQTT clients"]
    WS["WebSocket clients"]
    PUB --> CFG
    SUB --> CFG
    JSP --> CFG
    JSC --> CFG
    KVG --> CFG
    KVP --> CFG
    CFG --> CORE
    CFG --> JSE
    CFG --> KVE
    SRVM -. provides .-> CORE
    SRVM -. provides .-> JSE
    SRVM -. provides .-> KVE
    MQTT --> SRVM
    WS --> SRVM

Why NATS over MQTT?

#

Core Messaging

#

• Pub/Sub — Publish to subjects, subscribe with wildcards (sensor.>, factory.*.temperature)
• Request/Reply — Synchronous RPC patterns for command-and-control flows
• Queue Groups — Automatic load balancing across multiple consumers
• Message Headers & TTL — Metadata and automatic expiration
• Automatic Reconnection — Handles network failures gracefully with cluster failover

JetStream — Persistent Streaming

#

For when messages must not be lost:

• Stream Management — Create, update, delete streams with configurable retention (limits, interest, work queue)
• Pull & Push Consumers — Flexible consumption patterns for different use cases
• Message Replay — Replay from a specific sequence, time, or “last per subject”
• Delivery Guarantees — At-least-once and exactly-once semantics

Key-Value Storage

#

A distributed key-value store for configuration, state, and metadata:

• CRUD Operations — Get, put, delete, purge
• Watch — Real-time notifications when values change
• TTL — Automatic expiration of stale entries
• History — Configurable revision history per key
• Compression — Value compression for large values

Embedded NATS Server

#

Run a full NATS server directly inside Node-RED — perfect for edge deployments:

• Zero external dependencies — No separate NATS installation needed
• MQTT Bridge — Accept MQTT connections alongside NATS
• WebSocket Support — Browser-based clients
• HTTP Monitoring — Health and metrics endpoints

Node Types

#

8 purpose-built nodes: nats-suite-server, nats-suite-publish (publish plus request/reply mode), nats-suite-subscribe, nats-suite-stream-publisher, nats-suite-stream-consumer, nats-suite-kv-get, nats-suite-kv-put, nats-suite-server-manager
